Oukeda PM Permanent Magnet Linear Stepper Motor 15 Deg 0.23A 4 Phase Φ25x16mm
Electrical Specification:
Manufacturer Part Number: OK25BY16-023A6-22N
Motor Type: PM Linear Stepper Motor
Phase: 4
Step Angle: 15 deg
Phase Current: 0.23 A
Phase Voltage:12VDC
Push Force at 100pps:>1.5Kgf(15N)
Phase Resistance: 53 ± 7% ohms(20 ℃)
No-load starting frequency:350 PPS
Inductance: 9 mH ± 20%
Insultation Class:E;
Physical Specification
Frame Size: Φ25 mm
Body Length: 16 mm
Maxium Travel:22mm
Step Increment:0.0417mm/step
Number of Leads:3
Lead Length: 70 mm
Weight: 37g;
.jpg "Oukeda PM Permanent Magnet Linear Stepper Motor 15 Deg 0.23A 4 Phase Φ25x16mm")
.jpg "Oukeda PM Permanent Magnet Linear Stepper Motor 15 Deg 0.23A 4 Phase Φ25x16mm")
.jpg "Oukeda PM Permanent Magnet Linear Stepper Motor 15 Deg 0.23A 4 Phase Φ25x16mm")
| Electrical Specification | |
|---|---|
| No. of Phase | 4 |
| Step Angle(deg.) | 15 deg |
| Phase Current(A) | 0.23A |
| Phase Voltage(V) | 12VDC |
| Physical Specification | |
| Body Length(mm) | 16 mm |
| Lead Length(mm) | 70mm |
| No. of Lead | 3 |
| Single Shaft/Dual Shaft | Dual Shaft |
| Travel(mm) | 22mm |
| Frame Size(mm) | Φ25 |
