Integrated Stepper Motor Nema 23 190 Ncm(269oz.in) with Controller ISC04 12-38VDC

Integrated Stepper Motor Nema 23 190 Ncm(269oz.in) with Controller ISC04 12-38VDC
NO.:ISC04-20
Post a review
Special Offer in May 2023:
  • $10 Off Over $150
  • $20 Off Over $300
  • $30 Off Over $500
  • $50 Off Over $800
  • $60 Off Over $1000
  • $80 Off Over $1500
  • Enjoy Discount at Checkout!
  • Valid Till May 31st, 2023
  • Note:No coupon code needed, please place order directly!
Our Price:$104.53
Quantity:- +

Bulk Price:
Qty.Range(unit) Price(unit) Discount
2 $99.30 5%
5 $97.21 7%
10 $94.08 10%
50 $88.85 15%
Add To Cart

Electrical Specifications:

  • Manufacturer Part Number: ISC04-20
  • Step Angle: 1.8 deg
  • Holding Torque: 190 Ncm(269oz.in)
  • Rated Current/phase: 2.8 A
  • Phase Resistance: 1.13 ohms
  • Inductance: 5.4 mH ± 20%(1KHz)

Physical Specifications:

  • Frame Size: 57 x 57 mm
  • Body Length: 96 mm
  • Shaft Diameter: Φ6.35 mm
  • Shaft Length: 21 mm
  • Weight: 1230 g

Driver Specifications:

  • Output Peak Current: 1.5 - 4 A
  • Input Voltage: 12 - 38 VDC
  • Speed control through external potentiometer 0. 75 - 1250 RPM
  • Isolation Resistance: More than 100 MΩ
  • Dielectric strength: 500VAC for 1MIN.

Connection

V+
GND
ENA
ON
H/L
DIR
Vr
SPD
Red
Black
Blue
White
Yellow
Green
Orange
Purple



Resources

Wholesale stepper motors and wholesale stepper motor drivers online with guaranteed quality and competitive price at Oyostepper.com!

Prev: Nema 23 Integrated Stepper Motor 126 Ncm(178.4oz.in) with Driver Controller ISC04 12-38VDC
Next: Nema 23 Integrated Stepper Motor w/ Controller ISC08 12-38VDC 300 Ncm(425oz.in)
Integrate Stepper Servo Motor Specification
Input Voltage (V) 12 - 38
Electrical Specification
Holding Torque (Ncm) 190
Holding Torque (oz.in) 269
Phase Resistance(ohm) 1.13
Rated Current (A) 2.8
Step Angle(°) 1.8
Stepper Driver Specification
Output Current(A) 1.5 - 4
Physical Specification
Body Length(mm) 96
Frame Size(mm) 57 x 57
Shaft Diameter(mm) 6.35
Shaft Length(mm) 21
