RT-65B MEANWELL 64.6W Triple Output Switching CNC Stepper Motor Power Supply
RT-65B MEAN WELL 64.6W Triple Output Switching Power Supply
Features
Brand MEANWELL
5V DC 5A output
AC input voltage range: 88 ~ 264VAC
Rated power: 64.6W
Universal AC input / Full range
Protections: Short circuit / Overload / Over voltage / Over temperature
Cooling by free air convection
LED indicator for power on
100% full load burn-in test
All using 105℃ long life electrolytic capacitors
Withstand 300VAC surge input for 5 second
High operating temperature up to 70℃
Withstand 5G vibration test
3 years warranty
Resources
Full Datasheet:RT-65.pdf
Wholesale stepper motors and wholesale stepper motor drivers online with guaranteed quality and competitive price at Oyostepper.com!
Power Supply Specification | |
---|---|
Max. Output Current(A) | 8, 3.5, 1 |
Power(W) | 64.6 |
Brand | MEANWELL |
Output Voltage(VDC) | 5, 12, -12 |
Input Voltage(VAC/VDC) | 88 - 264 / 124 - 370 |
PFC Function | No |
Input Frequency(Hz) | 47 - 63 |
Efficiency(%) | 76% |
Power Type | Switching Power Supply |
Dim.(LxWxH)(mm) | 129 x 98 x 38 |
