Nema 17 Stepper Motor Unipolar 1.8 Deg 15.8Ncm (22.4oz.in) 0.31A 12V 42x42x33mm 6 Wires
Special Offer in April 2024:
- 6% OFF on Total Order Amount!
- Enjoy Discount at Checkout!
- Valid Till April 20th, 2024
- Note:No coupon code needed, please place order directly!
Our Price:$11.62
This unipolar Nema 17 stepper motor with step angle 1.8deg and size 42x42x33mm. It has 6 wires, each phase draws current 0.31.0A at 12V, with holding torque 15.8Ncm (22.4oz.in).
Electrical Specification
- Manufacturer Part Number: 17HS13-0316S
- Motor Type: Unipolar Stepper
- Step Angle: 1.8 deg
- Holding Torque: 15.8Ncm(22.4oz.in)
- Rated Current/phase: 0.31A
- Voltage: 12V
- Phase Resistance: 38.5ohms
- Inductance: 21mH ± 20%(1KHz)
Physical Specification
- Frame Size: 42 x 42mm
- Body Length: 33mm
- Shaft Diameter: Φ5mm
- Front Shaft Length: 24mm
- Number of Leads: 6
- Lead Length: 300mm
- Weight: 220g
Connection
|
A+
|
O+
|
A-
|
B+
|
O-
|
B-
|
|
BLK
|
YEL
|
GRN
|
RED
|
WHT
|
BLU
|
Resources
- Full Datasheet: 17HS13-0316S.pdf
Wholesale stepper motors and wholesale stepper motor drivers online with guaranteed quality and competitive price at Oyostepper.com!
| Electrical Specification | |
|---|---|
| Bipolar/Unipolar | Unipolar |
| Holding Torque (Ncm) | 15.8 |
| Holding Torque (oz.in) | 22.4 |
| Inductance(mH) | 21 |
| Phase Resistance(ohm) | 38.5 |
| Rated Current (A) | 0.31 |
| Step Angle(°) | 1.8 |
| Physical Specification | |
| Body Length(mm) | 33 |
| Frame Size(mm) | 42x42 |
| Single Shaft/Dual Shaft | Single Shaft |
| Shaft Type | O |
| Shaft Diameter(mm) | 5 |
| Shaft Length(mm) | 24 |
| No. of Lead | 6 |
| Lead Length(mm) | 300 |
| Weight(g) | 220 |
- Connectors: Molex, Harwin, Tyco/AMP, JST etc.
- Lead wires & cables: Special lengths, Protective hose
- Shaft: Round, D-Cut, Cross drilled, Key-Way, Thread or Hollow
- Winding: Resistance, Inductance, Rated Current, etc.
No reviews
View History
