Mean Well SDR-120-24 CNC Power Supply 120W 24VDC 5A 115/230VAC with PFC Function DIN Rail Power Supply

Mean Well SDR-120-24 CNC Power Supply 120W 24VDC 5A 115/230VAC with PFC Function DIN Rail Power Supply
NO.:SDR-120-24
Post a review
Special Offer in April 2024:
  • 6% OFF on Total Order Amount!
  • Enjoy Discount at Checkout!
  • Valid Till April 20th, 2024
  • Note:No coupon code needed, please place order directly!
Our Price:$52.69
Quantity:- +

Bulk Price:
Qty.Range(unit) Price(unit) Discount
5 $50.06 5%
10 $49.00 7%
50 $47.42 10%
100 $45.84 13%
Add To Cart

SDR-120-24 MEAN WELL 120W 24VDC 5A 115/230VAC with PFC Function DIN Rail Power Supply



Features

Brand MEANWELL

24V DC 5A output

AC input voltage range: 88 ~ 264VAC

Rated power: 120W

150% peak load capability

Built-in active PFC function, PF>0.93

Protections: Short circuit / Overload / Over voltage / Over temperature

Cooling by free air convection

Can be installed on DIN rail TS-35/7.5 or 15

UL 508 (industrial control equipment) approved

BS EN/EN61000-6-2(BS EN/EN50082-2) industrial immunity level

Built-in DC OK relay contact

100% full load burn-in test

3 years warranty



Applications

Industrial automation machinery

Industrial control system

Mechanical and electrical equipment

Electronic instruments, equipments or apparatus

Household appliances



Resources

Full Datasheet: SDR-120-24.pdf

Wholesale stepper motors and wholesale stepper motor drivers online with guaranteed quality and competitive price at Oyostepper.com!

Prev: Meanwell NDR-480-24 Switching Power Supply 480W 24VDC 20A 115/230VAC DIN Rail Power Supply
Next: Mean Well SDR-240-24 CNC Power Supply 240W 24VDC 10A 115/230VAC with PFC Function DIN Rail Power Supply
Power Supply Specification
Max. Output Current(A) 5
Power(W) 120
Brand MEANWELL
Output Voltage(VDC) 24
Input Voltage(VAC/VDC) 88 - 264 / 124 - 370
PFC Function Yes
Dim.(LxWxH)(mm/in.) 40 x 125.2 x 113.5 / 1.57x 4.93 x 4.47
Input Frequency(Hz) 47 - 63
Efficiency(%) 91%
Physical Specification
Product Type POWER SUPPLY
